HP ProDesk 405 G2 Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure7 Push the latch and release the Slim ODD.
Figure8 Remove the Slim ODD form chassis.
Figure9 Unplug all cable conn. from PCA.
Figure10 Release 6 pcs screws from PCA
Figure11 Remove PCA from chassis
Figure12 Push the hooks on both sides and then pick up
the memory
