Power switch assembly
Description Spare part number
Power switch assembly 732756-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 84).
2. Remove the access panel (
Access panel on page 85).
3. Remove the front bezel (
Front bezel on page 86).
4. Rotate the drive cage to its upright position.
5. Disconnect the cable from the system board connector labeled PB/LED.
122 Chapter 6 Removal and replacement procedures: Small Form Factor (SFF)
