Hood sensor
Description Spare part number
Hood sensor 638816-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 36).
2. Remove the access panel (
Access panel on page 37).
3. Disconnect the cable from the system board connector labeled HSENSE (1).
4. Using a tool, remove the sensor from the slot by pushing it into the computer to remove it (2).
To install the hood sensor, reverse the removal procedure.
76 Chapter 5 Removal and replacement procedures: Tower (TWR)
