13. Rotate the slot cover retention latch back in place to secure the expansion card.
14. Connect external cables to the installed card, if needed. Connect internal cables to the system board, if
needed.
15. Replace the computer access panel.
16. If the computer was on a stand, replace the stand.
17. Reconnect the power cord and any external devices, and then turn on the computer.
18. Lock any security devices that were disengaged when the access panel was removed.
19. Recongure the computer, if necessary.
Drive positions
Drive positions
1 3.5-inch hard drive bay
2 9.5 mm slim optical drive bay
NOTE: The drive conguration on your computer may be dierent than the drive
conguration shown above.
Drive positions 21
