Figure 29 Use PH1 screwdriver to loose screws of
system fan and remove it
Figure 30 Use T-15 screwdriver to loose the screws of
speaker and remove it
Figure 31 Use 170II micro shear to cut two cable ties of
PSU cables from chassis
Figure 32 Use T-15 screwdriver to loose the screws of
PSU
