Cabling 45
Cabling
BBWC battery pack cabling
• Cache module cabling: Use the 24-inch BBWC battery pack cable.
• Mezzanine card cabling: Use the 11.5-inch BBWC battery pack cable.
Using the HP c-Class Blade SUV Cable
The HP c-Class Blade SUV Cable enables the user to perform server blade administration, configuration,
and diagnostic procedures by connecting video and USB devices directly to the server blade. For SUV
cable connectors, see "HP c-Class Blade SUV Cable (on page 11)."
Connecting locally to a server blade with video and
USB devices
Use the SUV cable to connect a monitor and any of the following USB devices:
• USB hub
