Cabling 47
Use a USB hub when connecting a USB diskette drive and/or USB CD-ROM drive to the server blade. The
USB hub provides additional connections.
1. Connect the HP c-Class Blade SUV cable to the server blade.
2. Connect the video connector to a monitor.
3. Connect a USB hub to one USB connector.
4. Connect the following to the USB hub:
o USB CD/DVD-ROM drive
o USB keyboard
o USB mouse
o USB diskette drive
Item Description
1 Monitor
2 USB CD/DVD-ROM drive or diskette drive
3 USB keyboard
4 USB hub
5 USB mouse
6 HP c-Class Blade SUV Cable
