System specifications 127
Item Description
I/O ports
• Front panel – Two USB ports
• Rear panel – PS/2 keyboard port, PS/2 mouse port, embedded NIC 1/shared
management NIC port, embedded NIC 2 port, serial port, management NIC
port, video port, and four USB ports
• Internal – STD USB port (SKT1), USB tape device port (USBCONN1), and TPM
connector (CN5)
Status LED indicators
• Front panel – UID, internal health, embedded NIC 1/2 activity/link, HDD
activity, and power/standby
• Rear panel – Management NIC link/activity, embedded NIC 1/2 link/activity,
and UID
• System board – Processor fan failure (fans 1–3), system fan (fan 4) failure,
system/processor OTP, and memory module failure
Server management
• Management NIC
• Dedicated internal health indicator
• Onboard hardware failure indicators
Thermal solution
•
heat sink
Three processor fans, one system fan
• One processor
• One PSU fan
Memory
Item Description
Number of DIMM slots Six
Memory controller Integrated in the Intel
processor
Memory configuration
mode
• Single channel mode
• Dual channel symmetric mode (interleaving)
• Dual channel asymmetric mode (non-interleaving)
Maximum DIMM
installation per channel
• When using UDIMMs, two modules per channel
• When using RDIMMs, three modules per channel
DIMM specifications
Size
MM
2Rx8
• 1 or 2 GB PC3-10600E UDI
• 2 GB PC3-10600R RDIMM
• 4 GB PC3-10600R 1x4GB
Transfer rate 1333, 1066, or 800 MT/s
NOTE: Memory transfer rate depends on the current memory configuration mode and processor installed.
