Illustrated parts catalog 22
Item Description Spare part number Customer self repair
1 SAS controller board 462594-001 Mandatory
1
2 Full-height/full-length PCI Express x16 riser
board
511808-001 Mandatory
1
3 Half-length/low-profile PCI Express x16 riser
board
511809-001 Mandatory
1
4 BBWC (Battery Back Write Cache) cable 488137-001 Mandatory
1
5 SAS cache battery option kit 398648-001 Mandatory
1
6 System board 576932-001 Mandatory
1
7 Memory module Mandatory
1
a) 1 GB PC3-10600E UDIMM 501539-001
b) 2 GB PC3-10600E UDIMM 501540-001
c) 4 GB PC3-10600E UDIMM 501541-001
d) 2 GB PC3-10600R RDIMM 501533-001
e) 4 GB PC3-10600, 1x4GB 2Rx8 501534-001
8 Processor (include alcohol pad and thermal
compound)
Mandatory
1
a) Intel Xeon L3406 600129-001
a) Intel Xeon X3470 590322-001
b) Intel Xeon X3460 590323-001
c) Intel Xeon X3450 590324-001
d) Intel Xeon X3440 590325-001
e) Intel Xeon X3430 590326-001
f) Intel Celeron G1101 600639-001
g) Intel Pentium G6950 600128-001
h) Intel Core i3-530 600133-001
i) Intel Core i3-540 600134-001
9 Heat sink 576933-001 Mandatory
1
10 500W power supply unit with cable assembly 506247-001 Mandatory
1
11 400W power supply unit with cable assembly 536403-001 Mandatory
1
12 Hot-plug HDD backplane board 570079-001 Mandatory
1
Mass storage devices Mandatory
1
13 Optical disc drive (9.5 mm, two-drive model)
a) SATA DVD-ROM drive 481430-001
