Removal and replacement procedures 59
To install the heat sink:
CAUTION: To prevent overheating or a possible system crash, use only a heat sink specified for your
ProLiant server.
1. If you are using a new heat sink, remove the cover protecting the preapplied thermal compound.
Be careful not to touch or scratch the thermal compound.
2. Install the heat sink.
a. Insert the spring-loaded screws into the system board holes (1).
b. Use the T10/T15 wrench to tighten the spring-loaded screws (2).
3. Reinstall the air baffle.
4. Perform the post-installation procedure.
