Illustrated parts catalog 20
Item Description Spare part
number
Customer self
repair (on page
5)
t) 600-GB 6GB/s, 10,000-rpm 507129-014 Mandatory
1
14 SATA Midline (MDL) Solid State Drives* — —
a) 60-GB, hot-plug 539557-008 Mandatory
1
b) 120-GB, hot-plug 539557-010 Mandatory
1
Cables
15 SATA power and data cable* 536398-001 Mandatory
1
16 Mini-SAS to SATA cable* 536396-001 Mandatory
1
17 Hard drive backplane sensor data cable* 536399-001 Mandatory
1
18 Power cord* 142258-001 Mandatory
1
19 8-to-4-pin extension cable* 613231-001 Mandatory
1
20 4-pin extension cable* 613232-001 Mandatory
1
Miscellaneous
21 Slimline optical drive bracket* 532475-001 Mandatory
1
22 Fan 536401-001 Mandatory
1
23 Power supplies — —
a) Power supply, 500-W 506247-001 Optional
2
b) Power supply, 460-W* 536404-001 Optional
2
c) Power supply, 400-W* 536403-001 Optional
2
d) Redundant power supply, 400-W* 532478-001 Optional
2
24 Power supply bracket 532473-001 Mandatory
1
25 Processor heatsink 536392-001 Optional
2
26 Fan clip 536402-001 Optional
2
27 System PSU cable clip* 613233-001 Optional
2
28 LFF hard drive cage (with backplane) 532114-001 Optional
2
29 SFF hard drive cage (with backplane)* 536400-001 Optional
2
30 Rack mounting tabs (2) 536407-001 Optional
2
31 Air baffle 572968-001 Mandatory
1
32 Access panel 507262-001 Mandatory
1
33 System battery* 234556-001 Mandatory
1
34 Cache battery* 398648-001 Mandatory
1
35 Capacitor pack* 587324-001 Mandatory
1
36 Rack rail kit* 573091-001 Mandatory
1
*Not shown
** If LVDIMMs are mixed with standard DDR3 DIMMs on the same server, the LVDIMMs operate at 1.5V. If there are
three LVDIMMs per channel, the LVDIMMs operate at 1.5V. LVDIMMs are only supported for use with the Intel®
Xeon® 5600 series of processors.
1
Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
