HP ProLiant DL320e Setup Guide

1 Prerequisites
Before you can configure this solution, you must meet the prerequisites for pre-installation, required
files, server or enclosure setup, and HP Insight Online access.
Pre-installation
Review the pre-installation checklist in Table 1 (page 6).
Table 1 Pre-installation checklist
NotesRequirementDone?
HP Passport is used in the following tasks:If you do not have an HP Passport account, create one for use with
HP Insight Online. You can create an account at the following
• “Verifying access to HP Insight Online”
(page 10)
website: https://passport2.hp.com/hppcf/createuser.do?
hpappid=sp4ts.
• “Run the Hosting Device Setup Wizard”
(page 14)
IMPORTANT: Make sure that you select your country/region when
you register for HP Passport. If the Insight Remote Support (Insight
RS) Hosting Device cannot detect the country/region by using the
information entered in the Hosting Device Setup Wizard, it uses the
country/region associated with your HP Passport account.
• “Verify the Insight Online experience”
(page 25)
HP Passport ID:
Web browser and version:Verify that a supported browser is available on the computer you
will use to log in to Insight RS, iLO, OA, and Insight Online.
• Insight RS:
Microsoft Internet Explorer 8.x and 9.x◦
◦ Mozilla Firefox 7.x and 8.x
• iLO
◦ Microsoft Internet Explorer 7, 8, and 9
◦ Mozilla Firefox 10 ESR
◦ Chrome
• OA
◦ Microsoft Internet Explorer 7, 8, and 9
◦ Mozilla Firefox 3.6 and 4
• Insight Online
◦ Microsoft Internet Explorer 7.0 or later
◦ Mozilla Firefox 3.0 or later
6 Prerequisites

HP ProLiant DL320e Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor code	SR0PH
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V2
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Motherboard chipset	Intel® C204
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal Design Power (TDP)	69 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	- \
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	12 TB
Number of HDDs installed	0
Memory slots	4x DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Graphics card	G200
Graphics card family	Matrox
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Power supply	350 W
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	65734
Intel TSX-NI version	0.00
Intel Identity Protection Technology version	1.00
On-board graphics card model	Not available

Weight and Dimensions

Depth	750 mm
Width	434.6 mm
Height	43.2 mm
