Removal and Replacement Procedures
2-40 Compaq ProLiant DL360 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: MicroMachine Part Number: 169616-006 Last Saved On: 12/31/01 11:05 AM
CAUTION: Some heatsinks have an integrated, plastic-covered thermal pad. In this case,
remove the plastic cover from the new heatsink to expose the adhesive side of the thermal
pad before placing the heatsink on the processor.
CAUTION: If you are installing 1.0-, 1.13- or 1.26-GHz processors, you must use the
appropriate heatsink for each processor socket. The heatsinks are labeled “Processor 1” and
“Processor 2.” Failure to install the proper heatsink may result in damage to the processor and
the system.
Reverse steps 1 through 6 to replace the processor.
