100 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
Identifying Hot-Plug Fans
Item Description Zone Configuration
1 Fan 1 Processor Redundant
2 Fan 2 Processor Primary
3 Fan 3 I/O Redundant
4 Fan 4 I/O and processor Primary (shared)
5 Fan 5 Processor Primary
6 Fan 6 Processor Primary
7 Fan 7 Power supply and
processor
Primary (shared)
8 Fan 8 Power supply Redundant
