Server Component Identification 103
Item LED Color
1 Amber
2 Green
For LED status information, refer to "Battery-Backed Write Cache Enabler LED
Statuses (on page 103
)."
Battery-Backed Write Cache Enabler LED Statuses
Server Status LED Status Battery Module Status
Server is on and has normal run
time
Green = On Fast charging
Green = Off Trickle charging
Amber = On A short exists in the connection of one or more of
the four button cells within the battery module
Amber = Blinking An open exists in the circuit between the positive
and negative terminals of the battery module
Amber = Off Normal
Server is on and is in the first 30
seconds after power up
Green = On
Amber = On
Temporary lock-out state; data was lost due to
cable being detached
Server is off and is in data
retention mode
Amber = Blinking every
15 seconds
User data held in write cache is being backed up
