26 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
3. Connect the power cord to the power supply.
4. Route the power cord through the cable management arm or power cord
anchor.
NOTE: If using the power cord anchor, be sure to leave enough slack
in the power cord so that the redundant power supply can be removed
without disconnecting the power cord from the primary power supply.
5. Lock the cable management arm into the operating position.
Power Supply Blank
To remove the component:
1. Unlock the hinge on the cable management arm and swing the arm away
from the power supply area.
CAUTION: To prevent improper cooling and thermal damage,
do not operate the server unless all bays are populated with either a
component or a blank.
2. Remove the power supply blank.
WARNING: To reduce the risk of personal injury from hot
surfaces, allow the power supply or power supply blank to cool
before touching it.
