86 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
Item Description LED Color Status
3 PCI Hot Plug fault LED
(slot 2)
Amber On = Expansion board failed
Off = Normal
4 PCI Hot Plug power LED
(slot 2)
Green On = Power is applied to the slot
Flashing = Power is cycling
Off = Power is not applied to the slot
5 RJ-45 link LED Green On = Linked to network
Off = Not linked to network
6 RJ-45 activity LED Green On or flashing = Network activity
Off = No network activity
7 UID LED button Blue On = Activated
Flashing = System remotely managed
Off = Deactivated
8 Power supply LED Green On = Power turned on and power supply functioning
properly
Off = One or more of the following conditions exists:
•
•
•
•
AC power unavailable
Power supply failed
Power supply in standby mode
Power supply exceeded current limit
