Network Controller The HP ProLiant DL380e Gen8 server offers the customer a quad-port NIC standard with the option to
upgrade with a variety of networking options.
HP Ethernet 1Gb 4-port 366i Adapter
Expansion Slots
Primary Riser
(Standard)
Expansion Slots
#
Technology Bus
Width **
Connector
Width
Form Factor Notes
1 PCIe Gen3.0 X4 X8 Full Length, Full
Height Slot
2 PCIe Gen3.0 X8 X16 Half Length, Full
Height Slot
3 PCIe Gen3.0 X8 X8 Half Length, Full
Height Slot
4 PCIe Gen2.0 X4 X8 Low Profile
** Indicates the number of physical electrical lanes running to the connector.
Primary Riser
(Riser with SAS)
Expansion Slots
#
Technology Bus
Width **
Connector
Width
Form Factor Notes
1 PCIe Gen3.0 X4 X8 Full Length, Full
Height Slot
2 PCIe Gen3.0 X8 X16 Half Length, Full
Height Slot
3 PCIe Gen3.0 NA NA NA Not available for
Riser with SAS
4 PCIe Gen2.0 X4 X8 Low Profile
** Indicates the number of physical electrical lanes running to the connector.
NOTE: This riser kit comes with B320i Smart Array controller which provides support for up to 8 SAS or
SATA drives and requires a SAS license key to support SAS drives.
Secondary Riser
(Optional)
Expansion Slots
#
Technology Bus
Width **
Connector
Width
Form Factor Notes
5 PCIe 3.0 X16 X16 Full length, full
height slot
6 PCIe 3.0 X8 X16 Half length, full
height slot
** Indicates the number of physical electrical lanes running to the connector.
NOTE: When populating slots on secondary riser (p/n 661628-B21), a second processor must be installed.
NOTE: Slot 5 supports up to 225w PCIe cards. An additional Graphic Card Power Adapter Kit is required
(663282-B21). See Option Section below for offering.
NOTE: Adding the rear drive cage negates the space required for secondary optional riser slots 5 & 6.
QuickSpecs
HP ProLiant DL380e Generation 8 (Gen8)
Standard Features
DA - 14328 Worldwide — Version 27 — December 16, 2013 Page 4
