Internal Storage Devices
One of the following
depending on Model
Diskette Drive None
Optical Drive Optional
DVD-ROM, DVD-RW
NOTE: This option available with all 8SFF or 8LFF drive bay models.
Hard Drives None ship standard
Drive Bays 8 SFF drive bays total with Optical Bay
Optional: +8SFF drive bay (total of 16SFF drive bays)
NOTE: The Optical Drive bay is not available with +8SFF drive bay optional
upgrade.
8 LFF drive bays total with Optical Bay
12 LFF drive bays total without Optical Bay
Optional: +2 Rear Drive Bays (LFF or SFF)
25 SFF drive bays total without Optical Bay
Optional: +2 Rear Drive Bays (LFF or SFF)
NOTE: Drive cage changes are not supported except for adding +8SFF to an
existing 8SFF drive cage.
NOTE: Adding the rear drive cage negates the space required for secondary
optional riser slots 5 & 6.
NOTE: All Pre-configured Models come populated with some hard drive blanks
installed. Should the customer need additional hard drive blanks, they can
order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or
P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit. These part numbers for
single HDD blanks below are also provided should the customer require
replacement HDD blanks for their server.
Maximum Internal
Storage
Hot Plug SFF SAS 32.4TB 27 x 1.2TB (with 25SFF drive cage + Rear 2SFF
drive cage)
Hot Plug SFF SATA 27.0TB 27 x 1TB (with 25SFF drive cage + Rear 2SFF drive
cage)
Hot Plug LFF SAS 56.0TB 14 x 4TB (with 12LFF drive cage + Rear 2LFF drive
cage)
Hot Plug LFF SATA 56.0TB 14 x 4TB (with 12LFF drive cage + Rear 2LFF drive
cage)
Hot Plug SFF SAS SSD 21.6TB 27 x 800GB (with 25SFF drive cage + Rear 2SFF
drive cage)
Hot Plug SFF SATA SSD 21.6TB 27 x 800GB (with 25SFF drive cage + Rear 2SFF
drive cage)
Hot Plug LFF SATA SSD 11.2TB 14 x 800GB (with 12LFF drive cage + Rear 2LFF
drive cage)
QuickSpecs
HP ProLiant DL380e Generation 8 (Gen8)
Standard Features
DA - 14328 Worldwide — Version 27 — December 16, 2013 Page 6

HP ProLiant DL380e Gen8 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
Memory slots	12
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	384 GB
Memory layout (slots x size)	1 x 4 GB
HDD size	- \
RAID levels	0, 1, 0+1, 5, 5+0
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Number of HDDs supported	8
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
PCI Express slots version	3.0
Power supply	460 W
Redundant power supply (RPS) support	-
Chassis type	Rack (2U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	698.5 mm
Width	445.5 mm
Height	87.4 mm
Weight	42990 g
