Page #40 background imageLoading...
Page #40 background image
HP ProLiant DL380p Gen8 12 LFF Configure-to-order Server
665552-B21
Factory Integrated Model ships with:
1 FlexibleLOM connector: (see Step 2: HP FlexibleLOM section below for NIC choices to
populate the embedded connector)
Smart Array P420i Controller w/ Zero Memory (ZM)
I/O slots - 3 Slots come standard:
Slot 1 - FL/FH x16 PCIe 3.0 (x16 connector)
Slot 2 - HL/FH x8 PCIe 3.0 (x8 connector)
Slot 3 - HL/FH x4 PCIe 2.0 (x8 connector)
Additional Slots may be added via selections from the PCI Information and
Options subsection
System Fans - 4 (2 additional fans included with second processor)
Drive Cage - 12LFF (with built-in expander)
USB - 4 Rear, 1 Front, 1 Internal, 1 SD slot
HP iLO Management Engine (standard)
NOTE:
Power Supply & Rail Kit not included - choose from Step 3 & 4 sections below
NOTE:
Customers cannot select the E5-2643 nor the E5-2637 v2 processor in this
configure-to-order model.
NOTE:
Processors consuming 115W power or greater require the use of DIMM blanks
and do not support LR or HC-DIMMs
NOTE:
This chassis comes with a built-in expander. All drives can be driven off of the
embedded P420i controller.
NOTE:
Customers must add a minimum of a 512MB controller cache module when
choosing this CTO server.
NOTE:
If a P822 controller is required, it cannot be populated in slot 3.
NOTE:
If a P421 controller is required, it cannot be populated in slot 1.
NOTE:
If a P430 controller is required, it cannot be populated in slots 3 or 4.
NOTE:
HyperCloud DIMMs, Q4000, and Q6000 options are not supported in this CTO
server.
NOTE:
Customer will not be able to get an optical drive, SID, second front USB, and ID
label.
HP ProLiant DL380p Gen8 25 SFF Configure-to-order Server
665554-B21
Factory Integrated Model ships with:
1 FlexibleLOM connector: (see Step 2: HP FlexibleLOM section below for NIC choices to
populate the embedded connector)
Smart Array P420i Controller w/ Zero Memory (ZM)
I/O slots - 3 Slots come standard:
Slot 1 - FL/FH x16 PCIe 3.0 (x16 connector)
Slot 2 - HL/FH x8 PCIe 3.0 (x8 connector)
Slot 3 - HL/FH x4 PCIe 2.0 (x8 connector)
Additional Slots may be added via selections from the PCI Information and
Options subsection
System Fans - 4 (2 additional fans included with second processor)
Drive Cage - 25SFF (with built-in expander)
USB - 4 Rear, 1 Front, 1 Internal, 1 SD slot
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14212 North America — Version 54 — December 20, 2013
Page 40
