Illustrated parts catalog 24
Item Description Spare part number
Customer self repair (on
page
6
)
j) 450-GB, 15,000-rpm, LFF, 6G, dual port 653951-001 Mandatory
1
k) 600-GB, 15,000-rpm, LFF, 6G, dual port 653952-001 Mandatory
1
l) 500-GB, 7,200-rpm, SFF, 6G, dual port 653953-001 Mandatory
1
m) 1-TB, 7,200-rpm, SFF, 6G, dual port 653954-001 Mandatory
1
n) 1-TB, 7,200-rpm, LFF, 6G, dual port 653947-001 Mandatory
1
35
Hot-plug solid state SATA* — —
a) 100-GB, SFF, MLC, 3G 653965-001 Mandatory
1
b) 200-GB, SFF, MLC, 3G 653966-001 Mandatory
1
c) 400-GB, SFF, MLC, 3G 653967-001 Mandatory
1
d) 100-GB, LFF, MLC, 3G 653968-001 Mandatory
1
e) 200-GB, LFF, MLC, 3G 653969-001 Mandatory
1
f) 400-GB, LFF, MLC, 3G 653970-001 Mandatory
1
36
Hot-plug solid state SAS* — —
a) 200-GB, SFF, SLC 653961-001 Mandatory
1
b) 400-GB, SFF, SLC 653962-001 Mandatory
1
c) 400-GB, SFF, MLC 653963-001 Mandatory
1
d) 800-GB, SFF, MLC 653964-001 Mandatory
1
Optical drives
37
Optical drive module 675601-001 Mandatory
1
38
Slimline 8x/24x DVD-ROM drive 652294-001 Mandatory
1
39
Slimline 8x DVD+R/RW drive* 652295-001 Mandatory
1
40
Optical drive bracket 532475-001 Mandatory
1
Cables
41
8 LFF ribbon Mini-SAS storage cable* 675609-001 Mandatory
1
42
8 or 16 SFF ribbon Mini-SAS storage cable* 675610-001 Mandatory
1
43
Miscellaneous cable kit* 725768-001 Mandatory
1
a) 25 SFF Mini-SAS SR cable — —
b) 12 LFF Mini-SAS SR cable — —
c) 12 LFF/25 SFF power cable — —
44
8 or 16 SFF Mini-SAS hard drive backplane to
storage card*
675611-001 Mandatory
1
45
8 LFF drive cage data cable* 733716-001 Mandatory
1
46
12 LFF drive cage data cable* 733717-001 Mandatory
1
47
25 SFF drive cage data cable* 733718-001 Mandatory
1
48
8 or 16 SFF drive cage data cable kit* 733719-001 Mandatory
1
49
8 LFF power cable* 675612-001 Mandatory
1
50
8 SFF power cable* 675613-001 Mandatory
1
51
Slim SATA cable* 675614-001 Mandatory
1
