HP 1200W Common Slot Platinum Hot Plug Power Supply Kit
Part Number
578322-B21
Input Voltage Range ( V rms )
100 to 240
Frequency Range (Nominal) ( Hz )
50/60
Nominal Input Voltage ( Vrms )
100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating
800 900 1200 1200 1200 1200 1200
Nominal Input Current ( A rms )
9.3 8.6 6.7 6.5 6.1 5.8 5.6
Maximum Rated Input Wattage Rating ( Watts )
889 989 1290 1290 1290 1290 1290
Maximum Rated VA ( Volt-Amp )
927 1031 1345 1345 1345 1345 1345
Efficiency ( % )
90 91 93 93 93 93 93
Power Factor
0.97
Leakage Current ( mA )
0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak )
30
Maximum Inrush Current duration ( mS )
10
Maximum British Thermal Unit Rating ( BTU-Hr )
3033 3375 4403 4403 4403 4403 4403
HP 1200W Common Slot -48VDC Hot Plug Power Supply Kit
Part Number
437573-B21
Input Voltage Range ( V rms )
36-72
Frequency Range (Nominal) ( Hz )
DC
Nominal Input Voltage ( Vrms )
36 48 72
Maximum Rated Output Wattage Rating
1200 1200 1200
Nominal Input Current ( A rms )
38 28 19
Maximum Rated Input Wattage Rating ( Watts )
1380 1350 1365
Maximum Rated VA ( Volt-Amp )
1380 1350 1365
Efficiency ( % )
87 89 88
Power Factor
N/A
Leakage Current ( mA )
N/A
Maximum Inrush Current ( A peak )
20 25 35
Maximum Inrush Current duration ( mS )
1 1 3
Maximum British Thermal Unit Rating ( BTU-Hr )
4713 4610 4662
NOTE:
To review typical system power ratings use the HP Power Advisor which is available online located at url:
www.hp.com/go/proliant-energy-efficient
or
www.hp.com/go/hppoweradvisor
Click on "ProLiant Servers"
Click on the Server of interest. Example: DL385 G7
Click on: "Power Calculator" link. (You may need to scroll down to see it)
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Power Specifications
DA - 13594 North America — Version 48 — March 25, 2013
Page 55
