Memory Bandwidth and Capacity
[DIMM Type] Registered DIMMs (RDIMMs) Load Reduced (LRDIMMs)
HPE SKU P/N 805347-B21 805349-B21 836220-B21 805351-B21 805353-B21 805358-B21
DIMM Rank Single Rank Single Rank Dual Rank Dual Rank Dual Rank Quad Rank
DIMM Capacity 8GB 16GB 16GB 32GB 32GB 64GB
Voltage Std Voltage 1.2V Std Voltage 1.2V Std Voltage 1.2V Std Voltage 1.2V Std Voltage 1.2V Std Voltage 1.2V
DIMM Native Speed (MT/s) 2400 2400 2400 2400 2400 2400
SLOTS THAT CAN BE POPULATED
48 slot servers 48 48 48 48 48 48
MAXIMUM CAPACITY (GB)
384 768 768 1536 1536 3072
POPULATED DIMM SPEED (MT/s)
1 DIMM Per Channel 2400 2400 2400 2400 2400 2400
2 DIMM Per Channel 2133 2133 2400 2400 2400 2400
3 DIMM Per Channel 1866 1866 1600 1600 2133 2133
Memory Speed
by Processor
Model
Processor Models Supported Memory Speeds
E5-4660v3, E5-4650v3, E5-4627v3, E5-
4669v3, E5-4655v3, E5-4667v3
2133/1866/1600MT/s
E5-4620v3, E5-4640v3 1866/1600MT/s
E5-4610v3 1600MT/s
E5-4655v4, E5-4650v4, E5-4660v4, E5-
4627v4, E5-4667v4, E5-4669v4
2400/2133/1866MT/s
E5-4620v4, E5-4640v4 2133/1866MT/s
E5-4610v4 1866MT/s
Standard and
Maximum
Memory
Capacity (Pre-
configured
Models)
Pre Configured
Models
Standard Memory Maximum Memory
Plus Optional Memory
Standard Memory
Replaced with
Optional Memory
E5-4640v4 128GB (8x16GB) 1408GB (40x32GB,
8x16GB)
3072GB (48x64GB)
E5-4640v3 128GB (8x16GB) 2688GB (40x64GB,
8x16GB)
3072GB (48x64GB)
E5-4620v4 64GB (4x16GB) 1472GB (44x32GB,
4x16GB)
3072GB (48x64GB)
E5-4620v3 64GB (4x16GB) 2880GB (44x64GB,
4x16GB)
3072GB (48x64GB)
E5-4610v4 32GB (2x16GB) 1504GB (46x32GB,
2x16GB)
3072GB (48x64GB)
E5-4610v3 32GB (2x16GB) 2976GB (46x64GB,
2x16GB)
3072GB (48x64GB)
QuickSpecs
HPE ProLiant DL560 Generation9 (Gen9)
Memory
DA - 15296 Worldwide QuickSpecs — Version 10 — 6.20.2016 Page 49
