QuickSpecs
HP ProLiant ML10 v2 Server
Pre-configured Models
c04567802 DA 15220 North America Version 1 March 30, 2015
Page 12
NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options
section of this QuickSpecs.
NOTE: HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be
shipped separately.
NOTE: Maximum speed supported depends on the CPU installed.
Please see Memory Population Table or the Online Memory Configuration Tool at: http://www.hp.com/go/ddr3memory-
configurator.
NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional
hard drive blanks, they can order more using P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit.
Entry Models
HP ProLiant ML10 v2
G32401P 4GB-U NHP 4 LFF
350W PS Entry Svr
814483-001
Processor(s)
(1) Intel® PentiumG3240 (3.1GHz/2-core/3MB/54W, HT) Processor
Cache Memory
3MB (1 x 3MB) L3 cache
Memory
4GB (1 x 4GB) PC3-12800E DDR3 UDIMM
Network Controller
HP Ethernet 1Gb 2-port 332i Adapter
Storage Controller
HP Dynamic Smart Array B120i Controller
Hard Drive
None
Internal Storage
4 LFF SAS/SATA HDD cage; includes 4 LFF hard drive blanks
Optical Drive
None
Power Supply
HP 350W Multi-Output Power Supply
Fans
One (1) Non-redundant system fan ships standard
Management
HP iLO Management Engine (standard on system NIC)
Optional: HP iLO Essentials or HP Insight Control
Form Factor
Micro ATX Tower (4U)
Warranty
Server Warranty includes 1-Year Parts.
HP ProLiant ML10 v2
G32401P 4GB-U B120i
NHP 4LFF 1x1TB 350W PS
Entry Server
814484-001
Processor(s)
(1) Intel® PentiumG3240 (3.1GHz/2-core/3MB/54W, HT)Processor
Cache Memory
3MB (1 x 3MB) L3 cache
Memory
4GB (1 x 2GB) PC3-12800E DDR3 UDIMM
Network Controller
HP Ethernet 1Gb 2-port 332i Adapter
Storage Controller
HP Dynamic Smart Array B120i Controller
Hard Drive
None
Internal Storage
4 LFF SAS/SATA HDD cage; includes 1x1TB SATA drive and 3 LFF hard drive
blanks
Optical Drive
None
Power Supply
HP 350W Multi-Output Power Supply
Fans
One (1) Non-redundant system fan ships standard
Management
HP iLO Management Engine (standard on system NIC)
Optional: HP iLO Essentials or HP Insight Control
Form Factor
Micro ATX Tower (4U)
Warranty
Server Warranty includes 1-Year Parts
Base Models
HP ProLiant ML10 v2 i3
4150 1P 4GB-U B120i
350W PS Svr
Processor(s)
(1) Intel® Core
TM
i3-4150 (3.5GHz/2-core/3MB/54W, HT)Processor
Cache Memory
3MB (1 x 3MB) L3 cache
Memory
4GB (1 x 4GB) PC3-12800E DDR3 UDIMM

Other manuals for HP ProLiant ML10 v2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProLiant ML10 v2 and is the answer not in the manual?

HP ProLiant ML10 v2 Specifications

General IconGeneral
Bus typeDMI
SteppingC0
FSB ParityNo
Scalability1S
Processor cache8 MB
Processor cores4
Processor modelE3-1220V3
System bus rate5 GT/s
Processor seriesIntel Xeon E3-1200 v3
Processor socketLGA 1150 (Socket H3)
Processor codenameHaswell
Motherboard chipsetIntel® C222
Processor frequency3.1 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus- MHz
Processor boost frequency3.5 GHz
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x8, 1x16, 2x4, 2x8
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)80 W
Compatible processor seriesIntel® Xeon®
Number of processors installed1
Thermal solution specificationPCG 2013D
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
HDD size3.5 \
HDD interface-
SSD interfaceSerial Attached SCSI (SAS)
Total storage capacity1000 GB
Maximum storage capacity24 TB
Memory slots4x DIMM
Internal memory8 GB
Memory clock speed1600 MHz
Graphics cardG200
DVD interface typeSATA
Graphics card familyMatrox
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
Serial ports quantity0
USB 2.0 ports quantity2
PCI Express slots version3.0
Performance managementHP iLO
Compatible operating systemsMicrosoft Windows Server\\r Canonical Ubuntu\\r Red Hat Enterprise Linux (RHEL)\\r SUSE Linux Enterprise Server (SLES)\\r VMware
Processor ARK ID75052
Intel Identity Protection Technology version1.00
Chassis typeTower (4U)
Power supply350 W
Operating altitude0 - 3048 m
Non-operating altitude0 - 9144 m
Storage temperature (T-T)-30 - 65 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)10 - 90 %
On-board graphics card modelNot available
Weight and Dimensions IconWeight and Dimensions
Depth475.2 mm
Width175 mm
Height368.2 mm
