Rear panel components
Figure -2 and the following table show and describe the components on the rear panel of the server.
Figure -2 [Rear panel components]
1 PSU fan 9 LAN port (RJ-45)
2 Serial port B 10 PCI slot covers
3 PS/2 mouse port 11 Kensington lock notch
4 PS/2 keyboard port 12 Power supply outlet
5 Serial port A 13 Rear system fan
6 Parallel port 14 Thumbscrew for access panel
7 Monitor port 15 Cable lock provision tab
8 Rear USB 2.0 ports 16 PCI expansion slot cover lock
System board components
Figure -3 and Table -1 show and describe the components on the system board.
Figure -3 [System board components]
Table -1 System board components
Item Component Code Description
1 U19 Super I/O
2 XMM1 - 4 DDRII slots
3 P70 CPU fan connector
4 U3 Intel E7230
5 XU1 Intel LGA775 CPU socket
6 P3 4-pin ATX CPU power connection
