Hardware options installation 47
3. Remove the access panel ("Access panel" on page 6).
4. Remove the slot cover retainer.
The thumbscrew may look different than shown.
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all PCI slots have either an expansion slot cover or an expansion board installed.
5. Remove the expansion slot cover.
IMPORTANT: It may be necessary to remove the slot cover next to the slot in which you are
installing a board.
