Components, parts and materials containing
radioactive substances
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Remove the side panel and remove the battery from the system board.
2. Capacitors in 550W power supply=> 2.5 cm () - Remove the power supply bracket from the system with a T-15 torx
driver, and to remove the PSU from PSU bracket with a T-15 torx driver. With a #2 Philips screw driver remove the
screws securing the top cover then locate the capacitors and pry from the PCB with a flat head screw driver or Long
Nose Plier () and dispose of properly.
3. Capacitors in 900W power supply=> 2.5 cm () - Remove the power supply bracket from the system with a T-15 torx
driver, and to remove the PSU from PSU bracket with a T-15 torx driver. With a #2 Philips screw driver remove the
screws securing the top cover then locate the capacitors and pry from the PCB with a flat head screw driver or Long
Nose Plier () and dispose of properly.
4. Locate Megacell an remove.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1 – System exploding drawing
Attachment 2 – System battery location
Attachment 3 – 550W PSU capacitor location
Attachment 4 – 900W PSU module capacitor location
Attachment 5 – Remove Megacell
EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
