Component identification 9
Rear panel LEDs and buttons
Item Description Status
1
UID button/LED Solid blue = Activated
Flashing blue (1 Hz/cycle per sec) =
Remote management or firmware
upgrade in progress
Off = Deactivated
2
NIC status LED Solid Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
3
NIC link LED Solid green = Link exists
Off = No link exists
