NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
HP SmartMemory
New HP SmartMemory now provides additional protection for your servers. With HP Authentication it can verify that you have true HP
Qualified Memory in your HP ProLiant Gen8 server. With HP SmartMemory your new HP ProLiant server can take advantage of
additional Gen8 enhancements in performance, durability and future manageability support through HP Active Health System
DDR3 memory population guidelines
For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
General Guidelines:
The HP ProLiant ML310e Gen8 Server has four memory slots
There are two channels per server with two DIMM slots per channel
Memory channel 1 consists of the two (2) DIMMs that are closest to the processor
Memory channel 2 consists of the two (2) DIMMs that are furthest from the processor
Different types of processors have different types of memory support.
Support for single/dual-rank 1333/1600 MT/s ECC UDIMM (unbuffered DIMMS)
The server supports up to 32 GB (4 x 8-GB) for Unbuffered DIMMs
No support for LRDIMMs;RDIMMs; Non-ECC UDIMMs
Do not install DIMMs if the processor is not installed
Populate DIMMs from heaviest load (double-rank) to lightest load (single-rank)
Non-ECC DIMMs are not supported
Always use HP qualified DIMMs
ML310e Gen8 Supported Memory Bandwidth and Capacity
DIMM Type
Unbuffered with ECC DIMMs (UDIMMs)
DIMM Rank
Single Rank (1R)
Dual Rank (2R)
DIMM Capacity
2GB 2GB 4GB 4GB 8GB 8GB
DIMM Native
Speed (MHz)
1333 1600 1333 1600 1333 1600
Voltage
LV
Std
LV
Std
LV
Std
SLOTS THAT CAN BE POPULATED
4 slot servers
4 4 4 4 4 4
MAXIMUM CAPACITY (GB)
*
8 8 16 16 32 32
POPULATED DIMM SPEED (MHz)
1 DIMM Per
Channel
1333 1600 1333 1600 1333 1600
2 DIMM Per
Channel
1333
**
1600 1333
**
1600 1333
**
1600
NOTE:
Memory speed is a function of the processor QPI bus speed. To realize the performance memory capabilities listed above HP
SmartMemory is required.
* Maximum capacity will vary based on individual server platform qualification schedule
** For HP SmartMemory, UDIMM is supported at 2DPC@1333 at 1.35V. Third party memory may only support up to 2DPC@1066 at
1.5V.
QuickSpecs
HP ProLiant ML310e Generation 8 (Gen8)
Memory
DA - 14339 Canada — Version 28 — April 18, 2014
Page 37
