Table 6 shows hardware commona lity between ML350 G5 models.
Table 6 Common ality between ML350 G 5 storage ser ver configurations
Feature Item
Server family
ProLiant ML350 G5
Processor
2.67 GHz dual-core Intel Xeon 5150, 1333 MHz FSB
Memory
1GB(2x512MB)PC2–5300FullyBufferedDIMMs
Chip set Intel 5000Z
Drive controller HP Smart Array E200i with 128 MB Battery-Backed Write Cache (BBWC)
RAID
Hardware RAID 0, 1, 5
Operating system
Windows Storage Server 2003 R2 Standard Edition
External storage
None
Expansion slots (6 total) One PCI-X 64–bit 133 MHz
Two PCI-X 64–bit 100 MHz
Three PCI-Express x4 (x8 connectors)
Hot plug cage
Six LFF SAS/SAT A
Hot plug back panel
Yes
Power supply (single, NHP) Two (redundant and hot-swappable)
Optical drive
DVD+R/RW (16X)
1.44 floppy disk drive
No
Fans
Two (redundant)
Video Integrated ATI m50 (embedded 16 MB memory)
I/O ports Six USB ports (2 front, 2 back, 2 inside)
One PS2 keyboard
One PS2 mouse
One serial port
One VGA
NIC
One embedded NC373i multifunction gigabit network adapter with TCP/IP
offload engine
Server management
One iLO 2 with dedicated network port
Chassis
5U tower
Factory image
HPProLiantML350G5StorageServersarepreconfigured with default storage settings and preinstalled
with the Windows Storage Server 2003 R2 Standard Edition operating system (OS). This section provides
additional d etails about the preconfigured storage.
Physical confi guration
All models of the ML350 G5 come with six SATA hard disk drives (HDDs) and are configured for
hardware RAID 5 using the HP Smart Array E200i drive controllers. The HDDs are hot-pluggable and
hot-swappable, meaning the drives can be removed and installed with the power on, and the controller
determines whether a rebuild of the drive is ne cessary.
The logical drives reside on all six physical disks as shown in Figure 6.TheDON’TERASEvolume
contains an image that is deployed onto the OS partition during system installation.
28
Storage server features a nd specifications
