HP Proliant ML350 Generation 3 - Page 44

Removal and Replacement Procedures
6. Press on the top of the expansion slot latch (1) and open the latch toward the rear of the
chassis (2).
7. Remove the expansion board (3).
8. Close the expansion slot latch.
9. Replace the expansion board retainer if the expansion board is not immediately being
replaced.
1
2
3
Figure 2-26: Removing the expansion board
To replace an expansion board, reverse steps 2 through 9.
HP ProLiant ML350 Generation 3 Server Maintenance and Service Guide 2-29
