HP Proliant ML350 Generation 3 - Network Interface Controller LEDs

Connectors, Switches, and LEDs
4-16 HP ProLiant ML350 Generation 3 Server Maintenance and Service Guide
•
•
•
Network Interface Controller LEDs
The NIC LEDs are located on the back of the server. They provide the following information:
The speed at which the network is being accessed
If the server is linked to the network
If there is current network activity
Refer to the HP Servers Troubleshooting Guide for more information on troubleshooting
network controller problems.
2
1
Table 4-8: Network Interface Controller LEDs
Item Description Status Condition
1 Activity Off No network activity
Green blinking Linked and activity on the network
2 Link Off No network link
Green Linked to network
Figure 4-7: Network Interface Controller (NIC) LEDs
