HP ProOne 600 G3 Disassembly Instructions

Standard Operation Procedure
Tabulator： Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：
Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification)
Qty.
Fixture list (Specification)
Qty.
Take out Center IO Door & unscrewing
9(1/1)
2017/5/23
1.00
1. Unscrew (× 5) all joints illustrated as Fig. 1 &
Fig. 3.
 Torsion: 4.0 ± 0.5 kgf.cm
 Take the screwdriver vertically to the screw
holes.
 Put the screws into the material box.
2. Take out Center IO Door (Fig. 2).
3. Take out Center Cover (Fig. 1).
Glove Requirements: Half-finger gloves
Fig. 3
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
2
3
5
4
Take out to
the right
IO Door
Pull out
vertically
Fig. 1
Fig. 2
1
K-LOCK
screw
