Standard Operation Procedure
Tabulator： Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：
Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification)
Qty.
Fixture list (Specification)
Qty.
Take out Rear Cover
1. Follow the direction of red arrow to push
Rear Cover (Fig. 1).
2. Follow the sequence to pull open Rear Cover
and take it out. (Fig. 1).
Operating sequence: Bottom side → Left
side → Right side.
Glove Requirements: Half-fingered gloves
2(1/1)
2017/5/23
1.00
Fig. 1
Right side
Bottom side
Left side
To Next Page
