EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 9 Disconnect MB main power and PSU fan cable
from
MB
Figure 10 Remove CPU power cable from MB
Figure 11 Remove PSU from MB
Figure 12 Loose PCI latch cover from chassis

Other manuals for HP rp5800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP rp5800 and is the answer not in the manual?

HP rp5800 Specifications

General IconGeneral
ProcessorIntel Core i3-2120 (3.3 GHz, 3 MB cache, 2 cores)
Memory4 GB DDR3
Storage500 GB SATA (7200 rpm)
Operating SystemWindows 7 Professional (64-bit)
PortsVGA, DisplayPort, serial, parallel, audio in/out, RJ-45
Power Supply240W
