EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure 5 Loose the clapboard from chassis
Figure 6 Remove the clapboard from chassis
Figure 7 Disconnect front PSU fan cable from MB
Figure 8 Remove front PSU fan from ODD cage
