Server component identification 9
Item Description Status
3 Internal health LED Green = System health is normal.
Amber = System is degraded. To identify the component in a
degraded state, refer to "System board LEDs (on page 14)."
Red = System critical. To identify the component in a critical
state, refer to "System board LEDs (on page 14
)."
Off = System health is normal (when in standby mode).
4 External health LED
(power supply)
Green = Power supply health is normal.
Amber = Power redundancy failure occurred.
Off = Power redundancy failure has occurred. When the server
is in standby mode, power supply health is normal.
5 NIC 1 link/activity LED Green = Network link exists.
Flashing green = Network link and activity exist.
Off = No link to network exists.
If power is off, view the LEDs on the RJ-45 connector for status
by referring to the rear panel LEDs ("Rear panel LEDs and
buttons" on page 11).
6 NIC 2 link/activity LED Green = Network link exists.
Flashing green = Network link and activity exist.
Off = No link to network exists.
If power is off, the front panel LED is not active. View the LEDs
on the RJ-45 connector for status by referring to the rear panel
LEDs ("Rear panel LEDs and buttons" on page 11).
