QuickSpecs
hp AlphaServer SC20
DA-10976 North America — Version 1 — May 24, 2002 14
Options
Step 5 – Mandatory − Select Storage Building Blocks (SBBs) and Options (continued)
Step 5a − Mandatory - Configure minimum SBBs required for booting the AlphaServer SC System (continued)
The Heavy Density Storage Building Block (SBB) includes:
• Dual HSG80 controller shelf
• Three split bus shelves, six Ultra3 cables
• Six fiber optic cables
• Two Fibre Channel host adapters (DS-KGPSA-CA), one for each boot node in first domain
• Space for up to 42 – 18.2-GB, 36.4-GB, or 72-GB 1-inch disk drives
• Two licenses each for:
- HSG80 Array Controller Software
- HSG80 Solution Software for Tru64 UNIX
- StorageWorks command console UNIX agents
- Advanced File System Utilities
Step 5b – Mandatory − Select disk drives
Number of domains
1 2 3 4 5
Number of required disk drives (must all be the same)
Select the type from the list below
Number of disk drives
5 10 15 20 25
18.2-GB 10K rpm Ultra3 SCSI Universal Hot Plug HDD 1-inch height
3R-A0585-AA
36.4-GB 10K rpm Ultra3 SCSI Universal Hot Plug HDD 1-inch height
3R-A0919-AA
72-GB 10K rpm Ultra3 SCSI Universal Hot Plug HDD 1-inch height
3R-A3050-AA
18.2-GB 15K rpm Ultra3 SCSI Universal Hot Plug HDD 1-inch height
3R-A1543-AA
36-GB 15K rpm Ultra3 SCSI Universal Hot Plug HDD 1-inch height
3R-A3079-AA
Step 5c – Mandatory − Select single switched Fibre Channel fabric
• Select the components for single non-redundant switched Fibre Channel connectivity. Fibre Channel switch is a single point of failure if only one
is selected (one domain). See step 5d for redundant fabric.
Number of domains
1 2 3 4 5
Description Part Number
Quantity Quantity Quantity Quantity Quantity
A
lphaServer SC RAID FC 8EL Switch, includes rack kit, seven
fixed-media short wave optical transceivers, one GBIC-based
port (GBIC to be ordered separately)
3X-SCFCA-AA
1 2 2 2 2
64-Bit PCI-to-Fibre Channel HBA for Tru64 DS-KGPSA-CA
0 2 4 6 8
Fiber optic cable 50/125, xx = (2,5,15,30.50) BNGBX-xx
0 2 4 6 8
Ethernet cable – connects Fibre Channel Switch to
management network
BN25G-03
1 2 2 2 2
