QuickSpecs
hp AlphaServer SC20
DA-10976 North America — Version 1 — May 24, 2002 16
Options
Step 6 − Optional – Communications
Ethernet
• Each adapter uses one PCI slot
• First two DS20L nodes in each domain have their PCI slots populated. Other DS20L nodes have one slot available
• Each node includes two ports (Onboard in DS20L and one 2-port Ethernet Adapter in ES40 or ES45 (3X-DE602-AA/BB))
• One port is reserved for Management Network
• One port is available for other use
Maximum # supported per node
DS20L
(except first two nodes in each
domain)
ES40
ES45
PCI 2-port 32/64-bit 10/100-Mb UTP FE Ethernet adapter (Twisted Pair)
1 2
3X-DE602-AA
PCI 2-port 32/64-bit 10/100-Mb UTP FE Ethernet adapter (Twisted Pair)
2
3X-DE602-BB
Cable for 10BaseT Twisted Pair connection, xx=length in meters
BN25G-xx
PCI Gigabit Ethernet adapter, UTP FE Ethernet adapter (Twisted Pair)
1 2
DEGPA-TA
PCI Gigabit Ethernet adapter, SC connectors, MMF − no boot support
1 2
DEGPA-SA
SC-SC dual Fibre Optic cable, mm, pp xx = length in meters
BN34B-xx
ATM
• Each adapter/controller uses one PCI slot
• First two DS20L nodes in each domain have their PCI slots populated. Other DS20L nodes have one slot available
• Contact your Account Manager if you require ATM
PCI-to-ATM 155 Mb adapter – Fibre
3X-DAPBA-FA
PCI-to-ATM 155 Mb adapter – UTP
3X-DAPBA-UA
PCI-to-ATM 622 Mb adapter – Fibre
3X-DAPCA-FA
HIPPI
• Each adapter/controller uses one PCI slot.
• First two DS20L nodes in each domain have their PCI slots populated. Other DS20L nodes have one slot available.
• Contact your Account Manager if you require HIPPI.
PCI to HIPPI host bus adapter (integrated) 40 MB/sec, LOADA
KZPHA-AX
