QuickSpecs
hp AlphaServer SC20
DA-10976 North America — Version 1 — May 24, 2002 28
Technical Specifications
Dimensions (H x W x D)
8.75 x 17.5 x 26.0 in/22.2 x 44.5 x 66.0 cm
(fits 8.75 in [5U] in standard H9A15-S cabinet)
Shipping Dimensions
28.8 x 24 x 40 in/73.2 x 60.7 x 101.6 cm
Management Server Rackmount
DS20E (each)
Part Number: DA-SCMAA-BA
Weight
When lifting: Nominal 80 lb/36 kg
Maximum 86 lb/39 kg
Nominal 84 lb/38 kg
Total added to cabinet (brackets,
slides, cables):
Maximum 88 lb/40 kg
Shipping Weight
Nominal 100 lb/45 kg
Maximum 110 lb/50 kg
Clearances
Operating See specific cabinet requirements
Service Minimum 4 ft/121.9 cm, 30 in/76.3 cm
withdrawal on rails
RAID Base Building Block 2
Drawer Rackmount
Dimensions (H x W x D)
17.75 x 18.0 x 26 in/44.45 x 46.0 x 66.0 cm
(fits 22.75 in [10U] standard RETMA cabinet)
Part Number: DA-SCDMA-AA
Shipping Dimensions
Mounted in Cabinet
Weight
Nominal 73 lb/33 kg When lifting
(heaviest individual component):
Maximum 73 lb/33 kg
Nominal 210 lb/95.5 kg Total added to cabinet (brackets,
slides, cables):
Maximum 210 lb/95.5 kg
Shipping Weight
Nominal 310 lb/141 kg
Maximum 310 lb/141 kg
RAID Base Building Block 3
Drawer Rackmount
Dimensions (H x W x D)
22.75 x 18.0 x 26 in/57.75 x 46.0 x 66.0 cm
(fits 22.75 in [13U] standard RETMA cabinet)
Part Number: DA-SCDHA-AA
Shipping Dimensions
Installed in Cabinet
Weight
Nominal 73 lb/33 kg
When lifting (heaviest individual
component):
Maximum 73 lb/33 kg
Nominal 288 lb/131 kg
Total added to cabinet (brackets,
slides, cables):
Maximum 288 lb/131 kg
Shipping Weight
Nominal 310 lb/141 kg
Maximum 310 lb/141 kg
