Item Component Spare part number
For use in South Korea 737219-AD1
For use in Spain 737219-071
For use in Switzerland 737219-BG1
For use in Taiwan 737219-AB1
For use in Thailand 737219-281
For use in Turkey 737219-141
For use in the United Kingdom and Singapore 737219-031
For use in the United States 737219-001
(2) Hinge assembly (includes 2 cables and 2 rubber feet) 736885-001
(3) Audio/USB board (includes audio jack, memory card reader, and USB port)
NOTE: The audio/USB board does not include the audio/USB board cable. The
audio/USB board cable is included in the Cable Kit, spare part number 736883-001.
See
Cable Kit on page 21 for more Cable Kit spare part information.
736894-001
(4) Power connector board:
NOTE: The power connector board does not include the power connector board cable. The power connector
board cable is included in the Cable Kit, spare part number 736883-001. See
Cable Kit on page 21 for more
Cable Kit spare part information.
For use on keyboard base models equipped with a hard drive (includes hard drive
connector, power connector, HDMI port, and USB port)
736895-001
For use on keyboard base models not equipped with a hard drive (includes power
connector, HDMI port, and USB port)
746493-001
(5) TouchPad 736880-001
(6) 500-GB, 5400-rpm, SATA, 5.0-mm hard drive (does not include hard drive
bracket, hard drive connector cable, or screws)
NOTE: The hard drive bracket, hard drive connector cable, and screws are included
in the Hard Drive Hardware Kit, spare part number 736884-001.
737957-005
(7) 3-cell, 33-Wh, 3.05-Ah, Li-ion battery for use only in the keyboard base
(includes cable)
723997-006
(8) Bottom cover (includes rubber feet) 736882-001
20 Chapter 3 Illustrated parts catalog
