6. Remove the back cover (3).
7. Remove the back cover.
Reverse this procedure to install the back cover.
Tablet battery
Description Spare part number
3-cell, 32-Wh, 2.96-Ah, Li-ion battery for use only in the tablet (includes cable) 723996-005
Before removing the tablet battery, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 34).
WARNING! To reduce potential safety issues, use only the battery provided with the tablet, a
replacement battery provided by HP, or a compatible battery purchased from HP.
CAUTION: Removing a battery that is the sole power source for the tablet can cause loss of
information. To prevent loss of information, save your work or shut down the tablet through Windows
before removing the battery.
Remove the tablet battery:
1. Remove the four Phillips PM2.0×3.0 screws (1) and the three Phillips PM2.0×2.5 broad head
screws (2) that secure the battery to the display assembly.
2. Release the battery (3) by lifting it and sliding it slightly to the left.
3. Disconnect the battery cable (4) from the system board.
36 Chapter 4 Removal and replacement preliminary requirements
