d. WWAN module (see WWAN module on page 43)
e. Volume button board (see
Volume button board on page 47)
Remove the wireless antenna cables and transceivers:
1. Disconnect the WLAN antenna cables (1) from the WLAN module.
2. Release the wireless antenna cables from the retention clips (2) and routing channel built into the
display assembly.
3. Detach the wireless antenna transceivers (3) from the display assembly. (The wireless antenna
transceivers are attached to the display assembly with double-sided adhesive.)
Reverse this procedure to install the wireless antenna cables and transceivers.
Removal and replacement procedures
59
