Recommended versionEarliest compatible ver-
sion
Model
6.1.2b
1
6.1.0dHP StorageWorks SAN Director 16 Port 8-Gb FC
blade (FC8-16)
6.1.2b
1
6.1.0dHP StorageWorks SAN Director 32 Port 8-Gb FC
blade (FC8-32)
6.1.2b
1
6.1.0dHP StorageWorks SAN Director 48 Port 8-Gb FC
blade (FC8-48)
6.1.2b
1
6.1.0dHP StorageWorks SAN Director 6 Port 10-Gb ISL
blade (FC10-6)
5.55.2.0a
Fabric Manager
2
10.1.410.0.2Data Center Fabric Manager
1
At the time of the Fabric OS 6.1.2b release, HP's latest supported firmware version is actually 6.2.1. HP recommends that
you upgrade to that version, if possible, to take advantage of new features and bug fixes. See the HP StorageWorks Fabric
OS 6.2.1 release notes for details.
2
Using HP StorageWorks Fabric Manager (FM) 5.5 or earlier with Fabric OS 6.1.1 or later can result in problems with Zoning,
Performance monitoring, SYSLOG configuration, FICON wizards, IOD Delay, AAA replication, Port enable/disable and other
functions. Unless you are using Admin Domains, HP recommends that you upgrade to HP StorageWorks Data Center Fabric
Manager (DCFM) 10.3.x to use with Fabric OS 6.1.1 or later. If you are using Admin Domains, HP recommends that you
downgrade Fabric OS to 6.1.0h.
4/256 SAN Director blade support
Fabric OS 6.1.2b is fully qualified and supports the Director blades listed in Table 3.
Table 3 4/256 SAN Director blade support matrix
Number of bladesDirector blade
Supported with any mix, and up to eight blades of each
type. No intermix restrictions. The 4/256 SAN Director
must run Fabric OS 6.0.0b or later to support the FC8-16
port blade, and Fabric OS 6.1.0a or later to support the
FC8-32 and FC8-48 port blades.
FC4-16
FC4-32
FC4-48
FC8-16
FC8-32
FC8-48
FC10-6
Up to four blades of this typeFC4-16IP (iSCSI blade)
Up to two blades of this type. Up to eight FR4-18i blades
can be installed if they are used only for FC Fast Write or
FCIP without routing.
FR4-18i (FCIP/FC Router blade)
HP StorageWorks Fabric OS 6.1.2b release notes 13
