DC SAN Director blade support
Fabric OS 6.1.2b is fully qualified and supports the DC SAN Director blades listed in Table 4.
Table 4 DC SAN Director blade support matrix
Number of bladesDirector blade
Supported with Fabric OS 6.0.0b and later with any mix
and up to eight blades of each type. No intermix
restrictions.
FC8-16
FC8-32
FC8-48
FC10-6
Not supported with the DC SAN DirectorFC4-16IP (iSCSI blade)
Supported with Fabric OS 6.0.0b and later with a
maximum of four blades of this type. Up to eight FR4-18i
blades can be installed if they are used only for FC Fast
Write or FCIP without routing.
FR4-18i (FCIP/FC Router blade)
Power supply requirements for Director blades
Table 5 lists power supply requirements for Director blades to provide full redundancy (220 VAC
power is assumed).
IMPORTANT:
Director blades must meet minimum Fabric OS levels to operate in the Director chassis. For example,
the FC8-32 is not supported in the 4/256 SAN Director with Fabric OS 6.0.x.
Table 5 Power supplies required for blades in Director chassis
DC SAN Director
1
4/256 SAN DirectorDirector blade
Two power suppliesTwo power suppliesFC4-16
FC4-32
FC4-48
FC8-16
FC8-32
Two power suppliesFour power suppliesFC8-48
FC10-6
Two power supplies. FC4-16IP blades are
not supported in the DC SAN Director.
Four power suppliesFR4-18i (FCIP/FC Router blade)
FC4-16IP (iSCSI blade)
1
The DC Director can operate with nominal power of 110 VAC. See the appropriate hardware reference guide for power
specifications.
14
