All 8-Gb switches (except 8-Gb SAN Switch for HP BladeSystem c-
Class and EVA4400 embedded switch module, which do not support
v6.1.2x)
Fabric OS version
Added the ability to change portcfgfillword to IDLE or ARB(FF) mode.
Regardless of the Fabric OS version that was previously installed, all ports
default to IDLE [mode 0]. However if they were changed to ARB(FF) [mode
1] manually, they remain in ARB(FF) mode. Can be changed by the user.
Fabric OS 6.1.2x
Note: HP does not support
Fabric OS 6.1.2c.
0—IDLE for Link Init, IDLE for fill word
1—ARB(FF) for Link Init, ARB(FF) for fill word (NOTE: not supported with XP
storage arrays)
Mode:
WebTools functionality moved to DCFM
The functionality that was moved from WebTools in 6.1.1 to DCFM is applicable to both DCFM
Professional and DCFM Enterprise. Table 8 describes these changes.
Table 8 WebTools functionality in DCFM
CommentsDCFMWebTools 6.1.0Function
Configure > Zoning
Reverse Find in the zoning dialog
provides the view of the zoned
and unzoned devices in the fabric
if all zone members are selected
for Find.
Zone AdminAdd unzoned devices
Configure > Zoning:
Reverse Find in the zoning dialog
provides the view of the zoned
and unzoned devices in the fabric
if all zone members are selected
for Find.
Device Tree and Topology:
Connected End Devices: Custom
display from the top level in the
main frame provides the device
tree and topology view for all the
zoned devices if all zones are
selected in the active zone
configuration.
Zone AdminAnalyze zone config
Configure > ZoningZone AdminDefine device alias
Configure > Zoning
The Compare dialog provides the
Storage-Host and Host-Storage
view in a tree representation that
is comparable to the Device
Accessibility Matrix when all
devices are selected.
Zone AdminDevice accessibility matrix
Monitor > Logs > EventsMonitor > Fabric eventsFabric events
HP StorageWorks Fabric OS 6.1.2b release notes 21
