Power supply requirements for Director blades
Table 4 lists power supply requirements for Director blades to provide full redundancy (220 VAC
power is assumed).
IMPORTANT:
Director blades must meet minimum Fabric OS levels to operate in the Director chassis. For example,
the FC8-32 is not supported in the 4/256 SAN Director with Fabric OS 6.0.x.
Table 4 Power supplies required for blades in Director chassis
DC SAN Backbone Director and
DC04 SAN Director
1
4/256 SAN DirectorDirector blade
Two power suppliesTwo power supplies
FC4-16
FC4-32
FC4-48
FC8-16
FC8-32
Two power suppliesFour power supplies
FC8-48
FC10-6
Two power supplies. The FC4-16IP
blades are not supported in the DC
SAN Backbone Director and DC04
SAN Director.
Four power supplies
FR4-18i (FCIP/FC Router blade)
FC4-16IP (iSCSI blade)
Two power supplies. Requires 220
VAC in the DC04 SAN Director.
Not supported
FS8–18 (DC Switch Encryption
FC blade)
1
The DC Director can operate with nominal power of 110 VAC. See the appropriate hardware reference guide for power
specifications.
Fibre Channel Routing scalability
For the latest Fibre Channel Routing (FCR) scalability support information, see the HP StorageWorks
SAN design reference guide, available at:
http://www.hp.com/go/sandesignguide
16
