4. c7000 enclosures only: lnstall the supplied coupler plate. (This allows you to install a separate
device in the upper bay above the Tape Blade, if required.) Align the slots, as illustrated, and
slide forward to lock into place.
Figure 13 Installing the coupler plate
.
NOTE:
If you need to return the Tape Blade for service, you must first remove the coupler plate.
See “Remove the coupler plate” on page 72 for further details.
NOTE:
c3000 enclosures require a mini divider. This is supplied with the enclosure. Refer to the
documentation provided with the enclosure for installation instructions.
Tape Blade 31
