Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly components on page 16.
(2) Keyboard/top cover (includes keyboard cable):
For a list of keyboard country codes, see Keyboard/top cover on page 43 or Keyboard/top cover on page 43.
For use in blue models 905569-xx1
For use in purple models 905570-xx1
For use in white models 910180-xx1
(3) TouchPad
For use in blue models 905691-001
For use in purple models 906174-001
For use in white models 910178-001
(4) TouchPad cable 905563-001
(5) RTC battery 857380-001
(6) Battery, 3-cell, 41-WHr, 3.615-AHr, Li-ion 844203-855
(7) Battery cable 905566-001
(8) Heat sink 907105-001
(9) WLAN module (Intel Dual Band Wireless-AC 7265 802.11 AC 2x2 WiFi + BT 4.2 Combo Adapter
(non-vPro)
793840-005
(10) Speakers (includes cable) 905565-001
(11) System board (includes a graphics subsystem with UMA memory, thermal grease, and thermal pads):
Intel Celeron N3060 processor, 2 GB system memory, 32 GB eMMC hard drive, and a non-
Windows operating system
905302-001
Intel Celeron N3060 processor, 2 GB system memory, 32 GB eMMC hard drive, and the Windows
10 operating system
905302-601
Intel Celeron N3060 processor, 32 GB eMMC hard drive, and a non-Windows operating system 905305-001
Intel Celeron N3060 processor, 32 GB eMMC hard drive, and the Windows 10 operating system 905305-601
Intel Celeron N3050 processor, 2 GB system memory, 32 GB eMMC hard drive, and a non-
Windows operating system
905304-001
Intel Celeron N3050 processor, 2 GB system memory, 32 GB eMMC hard drive, and the Windows
10 operating system
905304-601
Intel Celeron N3050 processor, 32 GB eMMC hard drive, and a non-Windows operating system 905306-001
Intel Celeron N3050 processor, 32 GB eMMC hard drive, and the Windows 10 operating system 905306-601
(12) Power button board 905579-001
(13) Power button board cable 905562-001
(14) Power connector (DC in) cable 810327-004
(15) Base enclosure
For use in blue models 905564-001
14 Chapter 3 Illustrated parts catalog
