To remove the access panel:
1. Remove the secure compartment cover (1). For more information, see
Removing the Secure USB
Compartment Cover on page 11.
2. Remove the stand, if it is installed. See
Removing the Stand on page 6 for more information.
3. Lay the unit flat on a stable surface with the right side up and the left side down.
4. Slide the access panel about 3 mm (1/8 inch) toward the top of the unit (2), and then lift the
access panel up and off the unit (3).
Figure 2-3 Removing the side access panel
To remove the metal side cover:
NOTE: You must remove the metal side cover to access internal components such as the battery or
the memory.
1. Remove the four screws that secure the metal side cover to the chassis (1).
2. Lift the metal side cover, rear side first, off the unit (2).
Figure 2-4 Removing the metal side cover
Removing and Replacing the Side Access Panel and Metal Side Cover
13

HP t510 Specifications

General

Processor cores	2
Processor model	U4200
Processor family	VIA Eden
Motherboard chipset	VIA VX900
Processor frequency	1 GHz
Storage media	Flash
Card reader integrated	No
Total storage capacity	1 GB
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Graphics card	Chromotion HD 2.0
Networking features	Gigabit Ethernet
Graphics card family	VIA
Dimensions (W x D x H) with stand	58.4 x 215.9 x 219.7 mm
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	-
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Audio system	24-bit
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China

Weight and Dimensions

Depth	215.9 mm
Width	58.4 mm
Height	209 mm
Weight	1490 g
